2012年度
第1回生体材料・医用デバイス研究開発コアセンター研究会
日時:平成24年12月10日(月)10:15-11:45
場所:新潟大学ベンチャー・ビジネス・ラボラトリー 1F
サイエンティフィックビジュアライゼーション室
タイトル(1) : Biomaterials for Orthopaedics
講演者: Professor Elizabeth Tanner
School of Engineering,
University of Glasgow, UK
タイトル(2) : Risk Fracture Prediction of the Osteoporotic
Bone
Using Finite Element Modelling
講演者: Dr Magnús K Gíslason
Department of Mechanical and
Aerospace Engineering,
University of Strathclyde, Glasgow,
Scotland, UK
講演概要:
Osteoporosis can be seen in Spinal Cord Injury (SCI)
patients where mechanical aspects instead of pathological cause the bone
erosion. SCI patients are commonly subjected to bone fractures, in
particular during movement from the wheelchair to the bed. There is a
clinical need to estimate the bone risk fracture in patients on a subject
specific basis in order to determine the type and the magnitude of loading
the patients can be subjected to. This can also have implications during
rehabilitation where functional electrical stimulation in conjunction with
a locomotive robot can be used to get the patients on their feet again and
mechanically load the skeletal frame under controlled conditions. Subject
specific finite element models of the tibia of SCI patients were created
and were compared to an able bodied control group. Scans were obtained
using a pQCT scan, where the images were imported into Mimics where edge
detection of the bone was carried out and a three dimensional finite
element model of the bone created. Material properties of the mesh were
obtained through the grey scale value of each image slice, connecting the
density, element stiffness as well as the ultimate stress of each element
together. Loading was applied to the models and the risk of fracture
calculated using Abaqus (v.6.11) and compared between the two
groups.
(世話役:田邊裕治,プラムディタ・ジョナス)
![]() 公演中のProf.Elizabeth Tanner先生 |
![]() 講演が終わって質問に回答しているDr.Gíslasonさん |
